Dash#
Dash is a productive Python framework for building web applications. Written on top of Flask, Plotly.js, and React.js, Dash is ideal for building data visualization apps with highly custom user interfaces in pure Python. It's particularly suited for anyone who works with data in Python.
Deploying#
Dash apps can be deployed with the
rsconnect-python
package.
rsconnect deploy dash -n myServer MyApiPath/
Example apps#
An example Dash app is available on GitHub.
To deploy the example with rsconnect-python:
git clone https://github.com/sol-eng/python-examples
rsconnect deploy dash -n <saved server name> --entrypoint app:app python-examples/dash-app/
There are also a number of Dash example apps available from Plotly. Some of them require Python 2; those examples cannot be deployed to Posit Connect, which requires Python 3.5 or higher. Please ensure that you run examples locally before deploying to Connect.
git clone https://github.com/plotly/dash-sample-apps
rsconnect deploy dash -n <saved server name> --entrypoint app:app dash-sample-apps/apps/<app name>/
When deploying a Dash app, ensure that you specify the correct entrypoint
for the specific app you are deploying.
The example applications in this section have their source code in a file named app.py,
and within that file, the Dash application object is named app. So the entrypoint
specified here is app:app. If the main source file or application object is named
differently, you will need to specify a different entrypoint so that Posit Connect
can locate the application object to serve. See the
documentation on entrypoints
for more information.
Warning
Do not pass the url_base_pathname parameter to the Dash application constructor
in your code. Posit Connect will set the base path to the correct location
for the deployed application.
Multi-page apps#
Using Dash Pages#
The Dash documentation includes an example of an app that consists of multiple pages and an index page for navigation. Multi-page apps use Dash Pages, a feature introduced in Dash version 2.5 (released on June 7, 2022). The recommended approach for deploying multi-page Dash apps on Connect is to use Dash Pages.
For example, your project could have the following structure:
- app.py
- pages
|-- analytics.py
|-- home.py
|-- archive.py
from dash import Dash, html, dcc
import dash
app = Dash(__name__, use_pages=True)
app.layout = html.Div([
html.H1('Multi-page app with Dash Pages'),
html.Div(
[
html.Div(
dcc.Link(
f"{page['name']} - {page['path']}", href=page["relative_path"]
)
)
for page in dash.page_registry.values()
]
),
dash.page_container
])
if __name__ == '__main__':
app.run_server(debug=True)
import dash
from dash import html, dcc, callback, Input, Output
dash.register_page(__name__)
layout = html.Div(children=[
html.H1(children='This is our Analytics page'),
html.Div([
"Select a city: ",
dcc.RadioItems(['New York City', 'Montreal','San Francisco'],
'Montreal',
id='analytics-input')
]),
html.Br(),
html.Div(id='analytics-output'),
])
@callback(
Output(component_id='analytics-output', component_property='children'),
Input(component_id='analytics-input', component_property='value')
)
def update_city_selected(input_value):
return f'You selected: {input_value}'
import dash
from dash import html, dcc
dash.register_page(__name__, path='/')
layout = html.Div(children=[
html.H1(children='This is our Home page'),
html.Div(children='''
This is our Home page content.
'''),
])
import dash
from dash import html, dcc
dash.register_page(__name__)
layout = html.Div(children=[
html.H1(children='This is our Archive page'),
html.Div(children='''
This is our Archive page content.
'''),
])
Without Dash Pages#
If you are using a version of Dash that is less than version 2.5, you will not be able to use the Dash Pages feature. Instead, you can use the dcc.Location feature as described in this example. To deploy a multi-page app on Posit Connect, you must use Dash's get_relative_path and strip_relative_path functions to implement the navigation.
For example, your project could have the following structure:
- app.py
- pages
|-- __init__.py
|-- index.py
|-- page1.py
|-- page2.py
from dash import Dash, dcc, html, Input, Output, callback
from pages import page1, page2, index
app = Dash(__name__, suppress_callback_exceptions=True)
server = app.server
app.layout = html.Div([
dcc.Location(id='url', refresh=False),
html.Div(id='page-content'),
html.Div([
dcc.Link('Go to Home', href=app.get_relative_path("/")),
html.Br(),
dcc.Link('Go to Page 1', href=app.get_relative_path('/page1')),
html.Br(),
dcc.Link('Go to Page 2', href=app.get_relative_path('/page2'))
])
])
@callback(Output('page-content', 'children'), Input('url', 'pathname'))
def display_page(pathname):
pathname = app.strip_relative_path(pathname)
if pathname == '':
return index.layout
elif pathname == 'page1':
return page1.layout
elif pathname == 'page2':
return page2.layout
else:
return '404'
if __name__ == '__main__':
app.run_server(debug=True)
from dash import html
layout = html.Div([
html.H3('Home page!'),
])
from dash import dcc, html, Input, Output, callback
layout = html.Div([
html.H3('Page 1'),
dcc.Dropdown(
{f'Page 1 - {i}': f'{i}' for i in ['New York City', 'Montreal', 'Los Angeles']},
id='page-1-dropdown'
),
html.Div(id='page-1-display-value'),
])
@callback(
Output('page-1-display-value', 'children'),
Input('page-1-dropdown', 'value'))
def display_value(value):
return f'You have selected {value}'
from dash import dcc, html, Input, Output, callback
layout = html.Div([
html.H3('Page 2'),
dcc.Dropdown(
{f'Page 2 - {i}': f'{i}' for i in ['London', 'Berlin', 'Paris']},
id='page-2-dropdown'
),
html.Div(id='page-2-display-value'),
])
@callback(
Output('page-2-display-value', 'children'),
Input('page-2-dropdown', 'value'))
def display_value(value):
return f'You have selected {value}'
Note
Content URL paths for multi-page Dash apps do not update based on a set vanity URL.
For example, setting your application vanity URL to /multi-page-dash/ will make the
index page available at that location, but /multi-page-dash/page-2 will not be accessible.
page-2 will only be accessible via the base content URL, .../content/{GUID}/page-2.
User meta-data#
Dash apps can access the username and the names of the groups of the current
logged in user by parsing the RStudio-Connect-Credentials request header.
Note
Your Dash app should access the RStudio-Connect-Credentials header value
via the flask.request object's headers property. This value is populated
from the HTTP_RSTUDIO_CONNECT_CREDENTIALS environment variable present in the underlying WSGI environ.
This simple Dash app shows how to access and use the user credentials from the
RStudio-Connect-Credentials header:
# -*- coding: utf-8 -*-
import json
import dash
import dash_core_components as dcc
import dash_html_components as html
import flask
from dash.dependencies import Input, Output
app = dash.Dash(__name__)
app.layout = html.Div([
dcc.Dropdown(
id="salutation",
options=[
{"label": "Hello", "value": "Hello"},
{"label": "Greetings", "value": "Greetings"},
{"label": "Aloha", "value": "Aloha"},
],
searchable=False,
clearable=False,
value="Hello"
),
html.P(id="greeting")
])
def get_credentials(req):
"""
Returns a dict containing "user" and "groups" information populated by
the incoming request header "RStudio-Connect-Credentials".
"""
credential_header = req.headers.get("RStudio-Connect-Credentials")
if not credential_header:
return {}
return json.loads(credential_header)
@app.callback(
Output(component_id="greeting", component_property="children"),
[Input("salutation", "value")]
)
def greeting(salutation):
user_metadata = get_credentials(flask.request)
username = user_metadata.get("user")
return "%s, %s." % (salutation, username or "stranger")
if __name__ == "__main__":
app.run_server(debug=True)
User and Group uniqueness#
Most environments have unique usernames where each user identifies a single
user and groups the name of the groups the user is a member of.
However, in large organizations with hundreds of users and groups, this may not be true. See the Admin Guide sections Credentials for Content for more information.
